U-2200 USB 5Gbps Type-C Multiport Adapter w/PD

Get a Quote ✎

2020/08/12

1x 1GbE RJ45 Port
2x USB 5Gbps Type-A port + 1x USB Type-C PD pass-through Port
1x VGA + 1x HDMI + 1x DVI Port
1x SD&microSD Card Reader

Ordering Code: U-2200
Part No: U3-C50-DS10-11-00012
Solution: VL103Q4+AG6320+VL817+RTL8153B+GL3224

The USB Type-C Multiport Adapter lets you connect your laptop to a HDMI/DVI and VGA displays, a Gigabit Ethernet network, two SuperSpeed USB 5Gbps Type-A devices and a SD/microSD card, while also connecting to a USB-C charging power adapter.

Features

Works with USB Type-C laptop
Data rate of USB Type-A port: 5Gbps / 480Mbps /12Mbps / 1.5Mbps
Supports upstream charging of laptop
Supports jumbo frame up to 9k bytes
Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Supports 10/100/1000Mbps Ethernet
Compliant with HDMI 2.0, HDMI 1.4 and DVI 1.0
HDMI port supports UHD 3840x2160@30Hz
If both HDMI and DVI ports are connected to displays, only the HDMI port has output. Simultaneous HDMI/DVI and VGA video outputs (clone mode only)
SuperSpeed USB 5Gbps SD/microSD Card Reader
Supports Hot Plug Detection

Ordering Code	U-2200
Description	USB 5Gbps Type-C Multiport Adapter w/PD
Solution	VL103Q4+AG6320+VL817+RTL8153B+GL3224
Bus Type	USB 5Gbps
OS Driver Support	Windows 7/8/8.1/10/11 (32/64 bit) Mac OS X 10.8 or later Linux 2.6.24 or later
Connectors	1x 1GbE RJ45 2x USB 5Gbps Type-A Ports 1x USB Type-C PD Port 1x VGA Port 1x HDMI Port 1x DVI Port 1x SD Card Reader 1x microSD Card Reader
Data Rates	1Gb/100Mb/10Mb Ethernet USB 5Gbps
Resolution	3840x2160 @30Hz
Power Delivery	PD pass-through
Operating Temperature	0℃ – 45℃
Storage Temperature	-10℃ – 50℃
EMC Standards	CE, FCC
Dimensions	70L x 129W x 18.5H mm \| Cable 150mm
Package content	1x USB 5Gbps Type-C Multiport Adapter w/PD 1x User Manual
Packing Information	Retail Box Packing 40 pcs/Carton Measurment: 40L x 36W x 31H cm G.W: 8.6 Kg ; N.W: 8 Kg
