U-2190 USB 5Gbps Type-C Multiport Adapter w/PD
Get a Quote ✎
2020/05/20
- 1x HDMI Port + 1x VGA Port
- 2x USB 5Gbps Type-A Ports + 1x USB Type-C PD Port
- 1x 1GbE RJ45 Port
- 1x SD&Micro SD Card Reader
- Ordering Code: U-2190
- Part No: U3-C50-DS20-11-00012
- Solution: VL103Q4+AG6320+VL817+RTL8153B+GL3224
The USB 3.2 Type-C Multiport Adapter w/PD for use with a computer, extending functionality for connecting other devices.
Features
- Works with USB Type-C laptop
- Compliant to USB 3.0 Specification Revision 1.0 and Specification Revision 2.0
- Support upstream charging of laptop
- Supports jumbo frame up to 9k bytes
- Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
- Supports 100/1000Mbps Ethernet
- Compliant with HDMI 2.0, HDMI 1.4
- HDMI port support UHD 3840x2160@30Hz
- Simultaneously display via VGA outputs
- Supports Hot Plug Detection
| Ordering Code | U-2190 |
|---|---|
| Description | USB 5Gbps Type-C Multiport Adapter w/PD |
| Solution | VL103Q4+AG6320+VL817+RTL8153B+GL3224 |
| Bus Type | USB 5Gbps |
| OS Driver Support | Windows 7/8/8.1/10 (32/64 bit) Mac OS X v10.8 or later Linux 2.6.24 and 4.11.x or later |
| Connectors | 1x HDMI™ Port 1x VGA Port 1x 1GbE RJ45 Port 2x USB 5Gbps Type-A Ports 1x USB Type-C PD Port 1x SD Card Reader 1x Micro SD Card Reader |
| Data Rates | 1Gb/100Mb Ethernet USB 5Gbps |
| Resolution | 3840x2160 @30Hz |
| Power Delivery | PD pass-through |
| Operating Temperature | 0℃ – 45℃ |
| Storage Temperature | -10℃ – 50℃ |
| EMC Standards | CE, FCC |
| Dimensions | 70.2L x 129W x 18.5H mm | Cable 150mm |
| Package content | 1x USB 5Gbps Type-C Multiport Adapter w/PD 1x User Manual |
| Packing Information | Retail Box Packing 40 pcs/Carton Measurment: 40L x 36W x 31H cm G.W: 9.8 Kg ; N.W: 9.2 Kg |
Manual :
U-2190 User Manual
↧ DownloadDriver :
RTL_USB_ FE_GBE_Linux.zip
↧ DownloadRTL_USB_ FE_GBE_Windows.zip
↧ DownloadRTL_USB_ FE_GBE_Mac.zip
↧ DownloadQuestions & Answers :
Q: Why is there no display after connecting a USB Dock to an external monitor via HDMI, DisplayPort (DP), or VGA
Read More ›
